Velo S.P.A. Vertical Leaf & Tank Filter, Model CFV35, Stainless Steel
Product ID:PTA11909
Used- Velo S.P.A. Vertical Leaf & Tank Filter, Model CFV35, Stainless Steel. Tank approximate 48" diameter x 41" straight side, dished removable top on davit arm, coned bottom. (18) Vertical filters. Serial# V0018450, built 2010.
Velo S.P.A. Vertical Leaf & Tank Filter, Model CFV35, Stainless Steel
Product ID:PTA11910
Used- Velo S.P.A. Vertical Leaf & Tank Filter, Model CFV35, Stainless Steel. Tank approximate 48" diameter x 41" straight side, dished removable top on davit arm, coned bottom. (18) Vertical filters. Serial# V7988, built 2000.
Tank, Approximately 20,000 gallon, Stainless Steel, Vertical
Product ID:PTA11911
Used- Tank, Approximately 20,000 gallon, Stainless Steel, Vertical. Approximately 144" diameter x 300" straight side, dished top, sloped bottom. (4) Sidewall baffles, side bottom man way with cover, side bottom outlet. No manufacturers tag visible.
Mason Steel Tank, Approximately 2,500 Gallons, Stainless Steel, Vertical.
Product ID:PTA11920
Used-Mason Steel Tank, Approximately 2,500 Gallons, Stainless Steel, Vertical. Approximate 96" diameter x 74" straight side, dished top & bottom. Internal rated 14.9 psi at ambient temperature. Off center top entering Lightnin agitator, model 73-C-5, serial# 79073421, ratio 31.3, output rpm 56. Approximate 2-1/2" diameter shaft with a 4 blade turbine, driven by a 5hp, 3/60/230/460 volt, 1740 rpm motor. (3) 48" Tall side wall baffles. Openings top 1-1/2", 2", 4", 10" 18" man way with cover, 3" center bottom outlet. Mounts on carbon steel side lugs. Serial# T-4483-9A, built 1980.
